Solar Lithium Batteries

Li-ion EVE Solar & UPS Batteries

By Hybrid EV Engineering

Available Configurations:

• 24V 100Ah
• 48V 100Ah
• Custom Batteries on Order

Key Features:

• High-Quality EVE Cells
  • 3.2V 100Ah EVE LF100LA Prismatic LFP Cells
  • 5000+ Life Cycles for long-lasting performance
• Advanced Battery Management System (BMS)
  • Integrated DALY BMS with:
    • WiFi Connectivity for remote monitoring
    • Active Balancer ensuring optimal cell performance and longevity
• Lab-Tested Quality Assurance
  • Cells, BMS, and high-end accessories imported
  • Locally assembled and tested to ensure top-tier quality and performance
• 2-Year Backup Warranty
  • Peace of mind with guaranteed reliability and performance

EVE LF100LA Cell Specifications:

• Nominal Voltage: 3.2V
• Capacity: 100Ah
• Energy: 320Wh
• Initial Internal Resistance: ≤0.5mΩ
• Charging Cut-off Voltage: 3.65V
• Discharging Cut-off Voltage: 2.5V (T>0℃), 2.0V (T≤0℃)
• Standard Charging Current: 50A (0.5C)
• Max. Continuous Charge/Discharge Current: 100A (1.0C)
• Max. Pulse Charge/Discharge Current: 200A (2C for 30s)
• Cycle Life: 4000 cycles at 80% Depth of Discharge (DoD)
• Charging Temperature: 0℃ to 55℃
• Discharging Temperature: -20℃ to 55℃
• Dimensions: 118.5mm (H) x 160mm (W) x 50.1mm (T)
• Weight: 1.98 kg

Advantages of Li-ion EVE Batteries Over Imported Units:

• Faster delivery and local availability
• Superior after-sales support and service
• Customizable to your specific power needs
• Cost-effective with no hidden import fees

Why Choose Li-ion EVE Batteries?

• High Efficiency: Perfect for solar and UPS applications
• Longevity: Reliable, high-performance EVE cells
• Safety: Advanced DALY BMS with WiFi and active balancer

Power Your Future with Li-ion EVE Batteries—Quality You Can Trust, Locally Assembled!

EVE LF100LA Cell Specifications:

• Nominal Voltage: 3.2V
• Capacity: 100Ah
• Energy: 320Wh
• Initial Internal Resistance: ≤0.5mΩ
• Charging Cut-off Voltage: 3.65V
• Discharging Cut-off Voltage: 2.5V (T>0℃), 2.0V (T≤0℃)
• Standard Charging Current: 50A (0.5C)
• Max. Continuous Charge/Discharge Current: 100A (1.0C)
• Max. Pulse Charge/Discharge Current: 200A (2C for 30s)
• Cycle Life: 4000 cycles at 80% Depth of Discharge (DoD)
• Charging Temperature: 0℃ to 55℃
• Discharging Temperature: -20℃ to 55℃
• Dimensions: 118.5mm (H) x 160mm (W) x 50.1mm (T)
• Weight: 1.98 kg

Advantages of Li-ion EVE Batteries Over Imported Units:

• Faster delivery and local availability
• Superior after-sales support and service
• Customizable to your specific power needs
• Cost-effective with no hidden import fees

Why Choose Li-ion EVE Batteries?

• High Efficiency: Perfect for solar and UPS applications
• Longevity: Reliable, high-performance EVE cells
• Safety: Advanced DALY BMS with WiFi and active balancer

Updated Battery Specifications Including 12V 10Ah Configuration

Using the EVE LF100LA 3.2V 100Ah Prismatic LFP Cells as the base, here are the detailed specifications for all available battery configurations:

1. 12V 10Ah Battery (4 Cells)

• Nominal Voltage: 12.8V
  (3.2V × 4 cells)
• Capacity: 10Ah
• Energy: 128Wh (12.8V × 10Ah)
• Charging Cut-off Voltage: 14.6V
  (3.65V × 4 cells)
• Discharging Cut-off Voltage:
  • 10V (2.5V × 4 cells, T>0℃)
  • 8V (2.0V × 4 cells, T≤0℃)
• Standard Charging Current: 5A (0.5C)
• Max. Continuous Charging/Discharging Current: 10A (1.0C)
• Max. Pulse Current (30s): 20A (2C)
• Cycle Life: ≥4000 cycles @ 80% DoD
• Weight: ~7.92kg (1.98kg × 4 cells)

2. 24V 100Ah Battery (8 Cells)

• Nominal Voltage: 25.6V
  (3.2V × 8 cells)
• Capacity: 100Ah
• Energy: 2560Wh (25.6V × 100Ah)
• Charging Cut-off Voltage: 29.2V
  (3.65V × 8 cells)
• Discharging Cut-off Voltage:
  • 20V (2.5V × 8 cells, T>0℃)
  • 16V (2.0V × 8 cells, T≤0℃)
• Standard Charging Current: 50A (0.5C)
• Max. Continuous Charging/Discharging Current: 100A (1.0C)
• Max. Pulse Current (30s): 200A (2C)
• Cycle Life: ≥4000 cycles @ 80% DoD
• Weight: ~15.84kg (1.98kg × 8 cells)

3. 48V 100Ah Battery (15 Cells)

• Nominal Voltage: 48V
  (3.2V × 15 cells)
• Capacity: 100Ah
• Energy: 4800Wh (48V × 100Ah)
• Charging Cut-off Voltage: 54.75V
  (3.65V × 15 cells)
• Discharging Cut-off Voltage:
  • 37.5V (2.5V × 15 cells, T>0℃)
  • 30V (2.0V × 15 cells, T≤0℃)
• Standard Charging Current: 50A (0.5C)
• Max. Continuous Charging/Discharging Current: 100A (1.0C)
• Max. Pulse Current (30s): 200A (2C)
• Cycle Life: ≥4000 cycles @ 80% DoD
• Weight: ~29.7kg (1.98kg × 15 cells)

4. 51.2V 100Ah Battery (16 Cells)

• Nominal Voltage: 51.2V
  (3.2V × 16 cells)
• Capacity: 100Ah
• Energy: 5120Wh (51.2V × 100Ah)
• Charging Cut-off Voltage: 58.4V
  (3.65V × 16 cells)
• Discharging Cut-off Voltage:
  • 40V (2.5V × 16 cells, T>0℃)
  • 32V (2.0V × 16 cells, T≤0℃)
• Standard Charging Current: 50A (0.5C)
• Max. Continuous Charging/Discharging Current: 100A (1.0C)
• Max. Pulse Current (30s): 200A (2C)
• Cycle Life: ≥4000 cycles @ 80% DoD
• Weight: ~31.68kg (1.98kg × 16 cells)

Additional Features:

• DALY BMS with WiFi and active balancer for efficient monitoring and safety.
• Locally Assembled batteries with rigorous lab testing for quality assurance.
• Custom configurations are available on request.
